Keyboard

Legacy module

This is the original on-screen keyboard, kept under the Old category so older projects still load. For new patches use Keyboard (MIDI) under Controls, which has the same two plugs. There is also a Keyboard (MPE) for per-note expression, and an Old Keyboard (CV) that puts out voltages instead of MIDI.

The Keyboard module provides an on-screen piano keyboard, played with the mouse.

Inputs

Pin	Type	Description
Channel	Control	MIDI channel to send on

Outputs

Pin	Type	Description
MIDI Out	MIDI	MIDI note data

Usage Notes

• The keyboard is resizable
• Clicking the keyboard starts SynthEdit playback if it isn’t already running
• Playing from the computer keyboard is no longer supported — use the mouse, or a MIDI keyboard through MIDI In
