Comparator
The Comparator outputs a high voltage if Input A is greater than Input B, otherwise outputs a low voltage.
Inputs
Section titled “Inputs”| Pin | Type | Description |
|---|---|---|
| Input A | Audio | Signal to compare |
| Input B | Audio | Reference signal |
Outputs
Section titled “Outputs”| Pin | Type | Description |
|---|---|---|
| Output | Audio | High or Low output voltage |
Parameters
Section titled “Parameters”| Property | Description |
|---|---|
| Hi Out Val | Voltage output when A > B (default: 5V) |
| Lo Out Val | Voltage output when A ≤ B (default: -5V) |
